Radiography Imaging System

High-frequency X-ray unit eliminate soft radiation. allowing doctors and patients to absorb less radiation than conventional equipment.

Reduced exposure time, higher radiation safety standards, and longer tube life.

Almost no soft rays and stray radiation, high imaging quality.

Excelent stability, not affected by fixed voltage, no need for voltage regulator, smooth movement, fast and accurate positioning.

Quantity

Add to cart

Share :

High-frequency X-ray unit eliminate soft radiation. allowing doctors and patients to absorb less radiation than conventional equipment.

Reduced exposure time, higher radiation safety standards, and longer tube life.

Almost no soft rays and stray radiation, high imaging quality.

Excelent stability, not affected by fixed voltage, no need for voltage regulator, smooth movement, fast and accurate positioning.

  • Power Voltage: AC 11 0-240V
  • Frequency: 50160Hz
  • Maximum Power: 1100VA
  • Current: 5A
  • Fuse: iDA
  • Bulb Tube: CANON D-045
  • Ray Focal Spot: 0.4mm
  • Bulb Tube Voltage: 65KV± 10%
  • Anode Current: 7mA ± 20%
  • Anode Angle: 12.5°
  • Duty Cycle: 1/30
  • Half Value Layer: 65Kv
  • Inherent Filtration: ≥ 2.1mm Al
  • Leakage Radiation: 1 meter ≤ 0.1 4mGy/h
  • Time Of Exposure: O.01—2.Os

Technical Specification

Power Voltage Frequency Maximum Power Current Fuse Bulb Tube Ray Focal Spot Bulb Tube Voltage Anode Current Anode Angle Duty Cycle Half Value Layer Inherent Filtration Leakage Radiation Time Of Exposure
AC 11 0-240V 50160Hz 1100VA 5A iDA CANON D-045 0.4mm 65KV± 10% 7mA ± 20% 12.5° 1/30 65Kv ≥ 2.1mm Al 1 meter ≤ 0.1 4mGy/h O.01—2.Os
